RFloXa Hawk36 Max Fork

The RFloXa Hawk36 Max is a 228mm inverted front fork built for high-power electric dirt bikes. It is engineered around Arctic Leopard XE PRO S specs for a factory-level fit and geometry match on 19" and 21" wheel setups.

An inverted oil-spring damping system delivers smooth compression, controlled rebound, and front-end stability under hard braking and repeated impacts. Forged AL6061-T6 lower brackets and AL7075-T6 fork tubes with a MAX CNC-machined triple clamp interface keep it rigid and durable. Full tuning control covers high-speed compression, low-speed compression, rebound, and spring preload.

• Fitment: Arctic Leopard XE PRO S
• Wheel compatibility: 19" / 21"
• Center distance: 800mm
• Main piston travel: 228mm
• Tube diameter: Ø37mm
• Caliper mount spacing: 90mm
• Disc brake size: Ø220mm (upgradeable)
• Damping system: inverted oil-spring
• Adjustments: high-speed compression, low-speed compression, rebound, spring preload
• Materials: AL6061-T6 forged aluminum lower brackets, AL7075-T6 aluminum fork tubes, 55CRSI spring wire

Spring weight guide: 45lb: ≤85kg (≤187 lbs); 55lb: 85–120kg (187–265 lbs); 45–60lb progressive: 80–130kg (176–286 lbs).

The upper bearing is not pre-installed; the fork ships in standard configuration for compatibility across multiple setups. Genuine RFloXa suspension through our authorized dealer channel. Tell us your platform and rider weight and we confirm the right spec before it ships.
